OMEGA DWI-206 DS

توضیحات تکمیلی

Brand	OMEGA
Load cell	Excitarion voltage: 5 VDC Maximum load: Four 350 ohm load cells Connector :5-Pin Screw Terminal
Serial Port	Type : RS232C Communication rate: 9600 Baud Data format: 8 Data, 1 Stop bits, No parity Connector: 9-Pin D-Type male
Power Supply	Voltage: 12/15 VAC/DC@1000mA Frequency:50 Hz
Resolution	Display divisions: 10000 Divisions Internal divisions : 24 bits
Dimensions	Width : 96 mm Height: 96 mm Depth :80 mm Weight: 500 gr
Panel	Display: Dual Display Display Type: Six digits 19mm 7segments Keyboard type: 4 Micro Switch keys Annunciators: Set Points (A and B)
Enviroment	Storage temp: -10 C to +70 C Operating temp: +5 C to +40 C
Others	Input Command: 1Input 12VDC Output Command: Tow 220V-1A Relay Output
